Key Specifications/Special Features:
Main features:
Main screen: 15.6 inches 1366×768 IPS Screen capacitive 5 point glass screen touch screen angle adjustable
Customer screen: 9-inch 1280×720 HD screen, support two display showing difference
OS: Android 6.0 or above
CPU: RK3288 ARM Cortex-A17, quad core, 1.8GHz
DDR3: 2GB
SSD: 8GB
Camera: 1MP/2MP CMOS camera for face detection
Communication: Ethernet/WiFi/Bluetooth/2.0/3.0/4.0
Built-in wide dynamic 30-200 megapixels camera ID module, support face detection, human coincidence, app
Built-in printer paper: ø80x80mm print speed: 260mm/s auto- cutter function
External port: 5 USB 2 serial input 1 audio output 1 HDMI 1 access controlled port
Main screen: 15.6 inches 1366×768 IPS Screen capacitive 5 point glass screen touch screen angle adjustable
Customer screen: 9-inch 1280×720 HD screen, support two display showing difference
OS: Android 6.0 or above
CPU: RK3288 ARM Cortex-A17, quad core, 1.8GHz
DDR3: 2GB
SSD: 8GB
Camera: 1MP/2MP CMOS camera for face detection
Communication: Ethernet/WiFi/Bluetooth/2.0/3.0/4.0
Built-in wide dynamic 30-200 megapixels camera ID module, support face detection, human coincidence, app
Built-in printer paper: ø80x80mm print speed: 260mm/s auto- cutter function
External port: 5 USB 2 serial input 1 audio output 1 HDMI 1 access controlled port
| Specification/Features | |
| Item No. | GC-065V (Android, RK3288) |
| Feature/Advantage | Dual screen all in one Android facial recognition device, visitor registration,customer flow volume collection and analysis |
| Casing/Material | ABS, PCBA, color: pearl white |
| Platform | Application firmware, apps to be developed by customers |
| Operation System | Android 6.0 |
| 2D code decoding | with built-in 2D code decoding software, based on Android 6.0 |
| CPU | RK3288 ARM Cortex-A17,quad core,1.8GHz |
| Memory | DDR3 2GB (256*16 high speed cache chip, 4 pcs) |
| Nandflash: EMMC 8GB,24bit ECC, 16GB optional | |
| Operation display | 15.6 inch IPS RGB TFT,1920*1080 pixel, Aspect ratio:16:9 |
| or 15.6 inch IPS RGB TFT,1366*768 pixel, Aspect ratio:16:9 | |
| G+G capacitive 10 point touch, glass polishing,waterproof | |
| Customer display | 9″RGB TFT,1280*720 pixel, Aspect ratio:16:9, LVDS interfece |
| 2D code camera module | 1 Mega pixel, CMOS camera,720P |
| Fixed focal length lens | |
| Password keypad | UnionPay approve, support magnetic card, IC card, Quick Pass, Apple pay(external equipment, optional) |
| NFC card reader(optional) | 13.56MHZ contactless, meet standard of philip Mifare 1K/4K, ISO/IEC14443A/B, ISO/IEC15693, Mifare DESfire, Sony Felica |
| Commucation module | Optional, 3G module, 850/900/1800/1900MHz, WCDMA/HSDPA/EDGE/GPRS, 4G/LTE |
| WiFi module: IEEE802.11b/g/n compatible with wapi (optional) | |
| Bluetooth: support 2.0+EDR, 3.0, 4.0 | |
| Ethernet(RJ45), support TCP/IP HTTP protocols | |
| iBeacon: WeChat shake(Optional) | |
| (Optional)WiFi probe, customer flow volume collection and analysis | |
| Printer | High speed automatic paper cutting thermal printer, |
| Paper width: 80mm, printing speed: up to 10cm/s | |
| can print text, image, bar code with setting size and font | |
| Antenna | Built-in high gain antenna |
| Multi-media function | Highly efficient DSP processing, music, support mp3, wma and etc, support lyric display line by line or full display |
| Video, support 4k,H.265, HDMI 2.0,video enhancement | |
| Picture, jpeg, jpg, bmp, gif, jfif, support upto 8000*8000 pixel | |
| External interface
(may vary for different product batch,OEM available) |
USB 2.0: 2 pc, USB 2.0: 2pcs, mini USB OTG: 1pc |
| TF card slot(support up to 32GB) 1 pc | |
| Rs232 serial port, standard DB9 1pc, output 5V, 1A | |
| Ethernet RJ45 port, 2pcs, support TCP/IP HTTP protocol | |
| RJ11, 2 pcs, with incall information detection(optional) | |
| Earphone port, 1 pc | |
| Audio input port, 1 pc | |
| DC power socket(24V, 4A) 1pc | |
| DC switch 1pc | |
| Accessories | DC power adapter, input 100-240V, output, 24V, 4A |
| Built-in high gain antenna | |
| Working temperature | -10℃~50℃ |
| Storage temperature | -40℃~80℃ |
| Humidty | 95% without sticky |
| ESD protection | 12kv |
| Packing info | Box size:480*410*430mm Gross weight:9.5kg Qty/carton: 1pc/ctn Weight: 17kg |
