3.5Tons Forklift with 6m Lifting Height
|
Main Characteristics |
|||
|
Powerful engine Low center of gravity, small turning radius, more stable and reliable Comfortable seat for long-time operation Safe overhead guard Rear light for working in the dark Dual air filter Streamline balance weight Side shifter is optional Optional mast: 2-stage 3.3m/3.5m/4mmast; 3-stage4.5m/5m/5.5m/6m/7.3mmast Optional engine: EURO II/III China engine; DEUTZ-DACHAI engine; ISUZU engine;YANMAR engine. |
|||
|
Technical Parameters |
|||
|
Rated lifting capacity |
3500kg |
Load center |
500mm |
|
Power type |
Diesel |
Transmission |
Hydraulic |
|
Dimensions |
|||
|
Lifting height |
3000mm |
Free lighting height |
80 mm |
|
Turning radius |
2500mm |
Overall length |
3800mm |
|
Overall width |
1230mm |
Overall height (mast lowered) |
2110mm |
|
Overall height (mast raised) |
4270 mm |
Overall height (overhead guard) |
2110mm |
|
Fork length |
1220mm |
Fork width |
125mm |
|
Fork thickness |
50mm |
— |
— |
|
Performance |
|||
|
Max driving speed (with/without load) |
17/19km/h |
Max lifting speed (with load) |
375mm/s |
|
Max traction (with/without load) |
16/11kN |
Gradeability (with/without load) |
15/20% |
|
Tilting angles (forward/reverse) |
6/12° |
Service weight |
4580kg |
|
Engine |
|||
|
Engine model |
490BPG |
Engine power |
39kw |
|
Rated speed |
2650rpm |
Displacement |
2.67L |
|
No of cylinder |
4 |
— |
— |
|
Wheel |
|||
|
Front overhang |
465mm |
Wheelbase |
1700mm |
|
Front tread |
1000mm |
Rear tread |
970mm |
|
Front tire |
28×9-15 |
Rear tire |
6.50-10 |
|
The parameters are subject to change without notice |
|||
