4 axis cnc wood router 1325 wood carving cnc router rotary 3d wood working machines

4 axis cnc wood router 1325 wood carving cnc router rotary 3d wood working machines

Machine Main Specifications:

1)-Model: 1325(4*8feet)
2)-Structure: Seamless steel welded
3)-Table: Vacuum table with t slot
4)-XYZ working size: 1300*2500*200mm
5)-XYZ transmission: XY axis is helical rack and gear,Z axis Ball Screw
6)-XYZ guide rail: Famous Taiwan Hiwin Line 20mm Square guide way
7)-Spindle: 6kw air cooling spindle
8)-Spindle collet: 2 pieces
9)-Inverter: Well known china Fuling Inverter
10)-Motor: Servo motor
11)-Driver: Servo driver
12)-Controller system: DSP A18 control system
13)-Voltage: 220/380v, 3phase 50HZ
14)-Software: Artcam
15)-Router bits: 10pcs for free
16)-Lubrication: YES
17)-Packing weight: 1500KG

1325 CNC Machine Parts

Packing and Delivery

Machine packing and shipping pictures:

1. Outside package: Standard marine export plywood case.

2. inner package: Stretchy film and plastic film for humidity.
